Bow Type Drop Cable
Overview
Bow-type Drop cable is designed as drop cable in FTTx solution, it combines the advantages of indoor cable and self-supporting cable and is ideal products for FTTx scenarios.
The optical fiber unit is positioned in the center. Two parallel Steel Wires or Fiber Reinforced Plastics (FRP) are placed at the two sides. Then, the cable is completed with a black or color LSZH sheath.
Key Features
- Special low-bend-sensitivity fiber provides high bandwidth and excellent communication transmission property
- Two parallel FRP strength members ensure good performance of crush resistance to protect the fiber
- Simple structure, light weight, and high practicability
- Novel flute design, easily strip and splice, simplify the installation and maintenance
- Low smoke, zero halogen and flame-retardant sheath
Standards
- IEC332-1
- RoHS
Applications
- Aerial installation
- Indoor access
Specifications
General Specifications
|
Strength Member |
Cable Diameter (mm) |
Fiber Count |
Operating Temperature (℃) |
Cable Weight (kg/km) |
|
|
Steel Wire |
2.0*3.0 |
1-4 |
-20⁓+60 |
9.2 |
|
|
KFRP |
2.0*3.0 |
1-4 |
-20⁓+60 |
7.5 |
|
|
FRP |
2.0*3.0 |
1-4 |
-20⁓+60 |
7.2 |
|
Note: Customized cable structure is available
Mechanical Specifications
|
Strength Member |
Tensile Strength (N) |
Crush Resistance (N/100mm) |
Bending Radius (mm) |
|||
|
Short Term |
Long Term |
Short Term |
Long Term |
Dynamic |
Static |
|
|
Steel Wire |
200 |
100 |
2200 |
1000 |
60 |
30 |
|
KFRP |
80 |
40 |
500 |
100 |
60 |
30 |
|
FRP |
80 |
40 |
500 |
100 |
60 |
30 |
