Multi-purpose Breakout Cable (GJBFJH)
Overview
Multi-purpose breakout cable uses simplex cable (0.9mm tight buffer fiber, aramid yarn as strength member) as subunit. A fiber reinforced plastic (FRP) locates in the center of core as a non-metallic strength member. The subunits are stranded around the cable core. The cable is completed with a PVC or LSZH (Low smoke, Zero halogen, Flame retardant) jacket.
We select high-quality materials, reduce customer wiring and maintenance costs by strictly controlling key indicators of products, and provide guarantee for the long-term stability of connectors with excellent application performance.
Key Features
- Maximum core: 54
- Compact and stable structure
- Flame retardant, low smoke, non-toxic
- Stranded non-metallic strength member structure ensure the cable endure larger tensile strength
- Aramid yarn as strength member make cable have excellent tensile strength
- The outer jacket material has many advantages such as anti-corrosion, anti-water, anti-ultraviolet radiation, flame-retardant and harmless to environment etc.
- Anti-lightning strike, and anti-electromagnetic interference
- Easy install, easy mid-span access, sub-cable separate independent
Standards
- YD/T 1258.4
- RoHS
Applications
- Indoor any purpose cable distribution
- Backbone distribution cable in a building
Specifications
|
Fiber Count |
Cable Diameter (mm) |
Bending Radius (mm) |
Tensile Strength (N) |
Crush Resistance (N/100mm) |
Weight (kg/km) |
|||
|
Dynamic |
Static |
Short term |
Long term |
Short term |
Long term |
|||
|
2 |
7.0 |
140 |
70 |
300 |
150 |
1000 |
300 |
44 |
|
4 |
7.0 |
140 |
70 |
300 |
150 |
1000 |
300 |
45 |
|
6 |
8.5 |
170 |
85 |
660 |
330 |
1000 |
300 |
57 |
|
8 |
10.0 |
200 |
100 |
660 |
330 |
1000 |
300 |
76 |
|
12 |
12.5 |
250 |
125 |
660 |
330 |
1000 |
300 |
105 |
|
24 |
14.5 |
290 |
145 |
1320 |
400 |
1000 |
300 |
158 |
|
36 |
16.5 |
330 |
165 |
1320 |
400 |
1000 |
300 |
204 |
|
48 |
18.5 |
370 |
185 |
1320 |
400 |
1000 |
300 |
272 |
|
54 |
20.0 |
400 |
200 |
1320 |
400 |
1000 |
300 |
310 |
Note: Storage/Operating Temperature: -40℃-+70℃, customized cable structure is available
