S4800 Series Managed Switches
Overview
The Business S4800 Series Managed Switches, part of the Bland Business line of network solutions, is a portfolio of affordable managed switches that provides a critical building block for any small office network. Various management methods simplify network setup, and advanced features accelerate digital transformation, while pervasive security protects business critical transactions. The Bland Business S4800 Series Switches provide the ideal combination of affordability and capabilities for small office and helps you create a more efficient, better-connected workforce. When your business needs advanced networking features and security for the digital transformation yet value is still a top consideration, you’re ready for the Business S4800 Series Switches.
Key Features
|
|
|
|
|
|
Simplicity |
Security |
Performance |
Efficiency |
|
Plug-and-play and support various management methods. |
Pervasive security helps safeguards your network and the privacy of your customers. |
Gigabit Ethernet, multigigabit and wire-speed performance provide a solid foundation for small business network. |
Supports Energy Efficient Ethernet (IEEE 802.3az) standard, which optimizes power use to conserve energy without compromising performance. |
Standards
- IEEE 802.3 10BASE-T Ethernet, IEEE 802.3u 100BASE-TX Fast Ethernet, IEEE 802.3ab 1000BASE-T Gigabit Ethernet, IEEE 802.3ad Link Aggregation Control Protocol, IEEE 802.3z Gigabit Ethernet, IEEE 802.3x Flow Control, IEEE 802.1D (STP, GARP, and GVRP), IEEE 802.1Q/p VLAN, IEEE 802.1w Rapid STP, IEEE 802.1s Multiple STP, IEEE 802.1X Port Access Authentication, IEEE 802.3af, IEEE 802.3at, IEEE 802.1AB Link Layer Discovery Protocol, IEEE 802.3az Energy Efficient Ethernet.
Applications
- Small and Medium Enterprises, hotels, workgroups, campus access network
Specifications
|
Model Name |
S4800-8T-2G |
S4800-8P-2G |
S4800-24T-4G |
S4800-24P-4G |
|
Switching Capacity |
20Gbps |
20Gbps |
56Gbps |
56Gbps |
|
Packet Forwarding Rate |
14.88Mpps |
14.88Mpps |
41.66Mpps |
41.66Mpps |
|
MAC Address Table |
8K |
8K |
8K |
8K |
|
Total System Ports |
10 Gigabit Ethernet |
10 Gigabit Ethernet |
28 Gigabit Ethernet |
28 Gigabit Ethernet |
|
RJ-45 Ports |
8 Gigabit Ethernet |
8 Gigabit Ethernet |
24 Gigabit Ethernet |
24 Gigabit Ethernet |
|
Combo Ports (RJ-45 + SFP) |
2 SFP |
2 SFP |
4 SFP |
4 SFP |
|
Dimensions (W*D*H) |
280*180*44mm |
280*180*44mm |
440*208*44mm |
440*208*44mm |
|
Weight |
1.9Kg |
2.3Kg |
2.95Kg |
3.8Kg |
|
Power Supply |
AC:100⁓240V, 50⁓60Hz |
AC:100⁓240V, 50⁓60Hz |
AC:100⁓240V, 50⁓60Hz |
AC:100⁓240V, 50⁓60Hz |
|
PoE Power Budget |
- |
140W |
- |
370W |
|
Power Consumption |
≤7.35W |
≤163.2W |
≤20W |
≤430W |
|
Operating Temperature |
0℃⁓45℃ |
|||
|
Operating Humidity |
10%⁓90% relative, noncondensing |
|||
