50G QSFP28 Transceivers
High performance and cost-effective 50G QSFP28 optical transceivers, compatible with Cisco/Huawei/Juniper/H3C equipment.
Overview
Our 50G QSFP28 transceiver modules are designed for use in 50 Gigabit Ethernet links over Single Mode Fiber (SMF). They are compliant with QSFP28 MSA, and IEEE 802.3cd. They are compatible with different third-party vendors’ switches/routers/servers, etc. And they support data rate of 50Gbps and various transmission distance.
Features
- Supports 53.125Gbps aggregate bit rate
- Duplex LC receptacles
- Compatible with third-party (such as Cisco, Huawei, Juniper, H3C etc.) equipment
- Link length up to 10km/40km over Single Mode Fiber (SMF)
- Hot-pluggable capability
- Built-in digital diagnostic functions
- Low power consumption
- Single +3.3V power supply
- Operating case temperature: -5℃ to +70℃
Standards
- QSFP28 MSA
- IEEE 802.3cd/802.3bm
- RoHS
Applications
- Data Center
- 50G Ethernet
Specifications
|
Part Number |
Description |
Reach |
Wavelength |
Power Consumption (Max) |
Temperature |
DDMI |
|
T50G-QSFP-31LRCD |
50G QSFP28 LR |
10Km |
1310nm |
3.5W |
-5~70℃ |
Yes |
|
T50G-QSFP-31ERCD |
50G QSFP28 ER |
40Km |
1310nm |
3.5W |
-5~70℃ |
Yes |
|
T50G-QSFP-23LRCD |
50G QSFP28 BiDi LR |
10Km |
Tx:1271nm Rx:1331nm |
3.5W |
-5~70℃ |
Yes |
|
T50G-QSFP-32LRCD |
50G QSFP28 BiDi LR |
10Km |
Tx:1331nm Rx:1271nm |
3.5W |
-5~70℃ |
Yes |
Resources
|
T50G-QSFP-31ERCD Transceiver Datasheet |
