Voice XPON ONT
Overview
Our dual-mode voice XPON Optical Network Terminal (ONT) supports auto-access to EPON/GPON OLT. The ONT automatically switches into the corresponding PON mode by identifying the local OLT mode to complete GPON/EPON adaptive access.
It features high-performance forwarding capabilities to ensure excellent experience of data, voice, and High Definition (HD) video services. It also has good third-party compatibility to work with the third-party OLT, such as Huawei/ZTE/Nokia/FiberHome. It provides a perfect terminal solution and future-oriented service supporting capabilities for all-optical access deployment.
Network Topology
Application Scenarios
- FTTx: FTTO, FTTD, FTTH
- POL: Enterprise, Campus, Schools, Departments, Hotels, Industrial Park, Commercial Building, Video Surveillance, etc.
Features
|
|
|
|
|
Reduce cost |
Improve quality of service |
Accelerate time to market |
|
|
|
Standards
- ITU-T G.984
- IEEE 802.3ah
Specifications
|
Type |
HG3110 |
HG4210 |
HG4214L |
HG4215V |
HG4424L |
HG4414 |
|
NNI |
GPON |
G/EPON |
G/EPON |
G/EPON |
G/EPON |
G/EPON |
|
UNI |
1GE+1POTS |
2GE+1POTS |
1GE+1FE+1POTS+Wi-Fi 4 |
2GE+1POTS+Wi-Fi 5 |
1GE+3FE+2POTS+Wi-Fi 4 |
4GE+1POTS+Wi-Fi 4 |
|
Dimensions (W*D*H) |
137*83.5*26.5mm |
131*120*29mm |
185*120*34mm |
178*120*30mm |
205*140*37mm |
205*140*37mm |
|
Weight |
0.1Kg |
0.13Kg |
0.24Kg |
0.32Kg |
0.34Kg |
0.34Kg |
|
Power Supply |
DC:12V/1A |
DC:12V/1.5A |
||||
|
Power Consumption |
≤5W |
≤5W |
≤6W |
≤10W |
≤10W |
≤10W |
|
Operating Temperature |
0⁓+50℃ |
|||||
|
Operating Humidity |
10%⁓90% RH, non-condensing |
|||||
Resources
|
HG4210 Datasheet |
